Leading Solid Polycarbonate Sheet Manufacturer In China

Solid polycarbonate sheet offers high light transmission, excellent impact resistance, and extraordinary durability. It is virtually unbreakable as 250-300 times stronger than glass, 20-30 times stronger than plexiglass sheets, and 25 times stronger than tempered glass. Therefore, it is widely known as polycarbonate glazing sheet, polycarbonate sheet, polycarbonate panel, unbreakable plastic sheet, etc.

Click here

Solid Polycarbonate Specification

Thickness (mm)Width (mm)Length (m)
0.8mm, 1mm, 1.5mm1220mm, 2100mm, 2650mm1220mm, 2440mm, 5800mm, 11800mm, 30m (roll), 40m (roll), 50m (roll)
2mm, 2.5mm, 3mm, 4mm, 5mm, 6mm1220mm, 2100mm, 2650mm1220mm, 2440mm, 5800mm, 11800mm
8mm, 10mm, 12mm, 15mm1000mm, 1220mm, 2100mm, 2650mm1220mm, 2440mm, 5800mm, 11800mm
16mm, 18mm, 20mm1000mm, 1220mm, 2100mm1220mm, 2440mm, 5800mm
25mm, 30mm, 35mm, 40mm610mm, 1050mm, 1220mm1220mm, 2440mm
45mm, 50mm, 60mm, 70mm, 80mm, 90mm, 100mm, 200mm, 300mm, 400mm, 500mm610mm, 1050mm, 1220mm1220mm, 2440mm
TypeColors description
TransparentClear, Bronze, Red, Blue, Green, Solar Grey, Lighter Blue, Lighter Green
TranslucentWhite Opal, White Diffuser, Yellow, Red, Mint Green
OpaqueBlack, Yellow, Dark Blue, Cream, Dark Grey, Dark Brown
PropertyTest MethodTesting ConditionUnitValue
DensityD-792 g/cm31.2
Heat Deflection TemperatureD-648Load: 1.82 MP°C135
Short Time Service Temperature  °Cfrom -50 to +130
Long Time Service Temperature  °Cfrom -40 to +100
Coefficient of Linear Thermal ExpansionD-696 mm/m °C0.065
Thermal ConductivityC-177 W/m K0.21
Tensile Strength at YieldD-63810 mm/minMpa or N/mm²>65
Tensile Strength at BreakD-63810 mm/minMPa or N/mm²>60
Elongation at YieldD-63810 mm/min.%6
Elongation at BreakD-638 %>95
Tensile Modulus of ElasticityD-6381 mm/minMPa2350
Flexural StrengthD-7901.3 mm/min.MPa100
Flexural ModulusD-7901.3 mm/min.MPa2600
Impact Falling WeightISO 6603/1 E503mm sheetJ158
Light TransmissionD-1003 %82 – 92
HazeD-1003 %<0.5
Flammability RateUL 94  V-2
