Flame retardant Polycarbonate Sheet Introduction
Flame Retardant Polycarbonate offers improved fire resistance and heat deflection characteristics over the standard polycarbonate sheet. It meets the flammability codes of the engineering industry, construction industry, and transportation industry, such as UL94, ASTM E84, GB/T2408-2008, UL723, etc. Some people call it Fire Resistant Polycarbonate and Fireproof Plastic.
Flame Retardant Polycarbonate Specification
| Thickness (mm) | Width (mm) | Length (m) | Packaged as Panel | Packaged as Roll |
|---|---|---|---|---|
| 0.125mm | 1220 | 2.44, 400 |  | |
| 0.175mm | 1220 | 2.44, 350 | | |
| 0.25mm | 1220 | 2.44, 300 | | |
| 0.375mm | 1220 | 2.44, 200 | | |
| 0.5mm | 1220 | 2.44, 150 | | |
| 0.75mm | 1220 | 2.44, 100 | | |
| 1mm, 1.5mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 30, 40 | | |
| 2mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 30 | | |
| 2.5mm, 3mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12, 20 | | |
| 4mm, 5mm, 6mm, 8mm, 10mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12 | | |
| 8mm, 10mm, 12mm, 15mm | 1000, 1220, 2100, 2650 | 2.44, 5.8, 12 | | |
| 16mm, 18mm, 20mm | 1000, 1220, 2100 | 2.44, 5.8 | |
| Physical Property | Testing Method | Unit | Value |
|---|---|---|---|
| Specific Gravity | D-792 | g/cm3 | 1.2 |
| Coefficient of Linear Thermal Expansion | D-696 | mm/m °C | 0.065 |
| Thermal Conductivity | C-177 | W/m K | 0.21 |
| Tensile Strength at Yield | D-638 | Mpa or N/mm² | >60 |
| Tensile Strength at Break | D-638 | MPa or N/mm² | >65 |
| Elongation at Break | D-638 | % | >100 |
| Tensile Modulus of Elasticity | D-638 | MPa | 2400 |
| Flexural Strength | D-790 | MPa | 100 |
| Fire rating | UL 94 | / | V2/V0 |
| Fire rating | ASTM E84 | / | Class B or Class A |
| Light transmittance | D-1003 | % | From 80% to 91% |
| Type | Colors Description |
|---|---|
| Transparent | Clear, Bronze, Brown, Gary, Red, Lighter Blue, Lighter Green |
| Translucent | Black, Opal White, Blue, Green |
| Opaque | Black, Opal White, Yellow, Dark Blue, Red, Dark Grey, Dark Brown |
Main Benefits of Flame Retardant Polycarbonate
Typical Applications
Related Products
Frequently Asked Questions
Our main products are PVC roof sheets, Polycarbonate Sheets, FRP sheets, etc.
Of course, we can send you our samples for free. We only need your courier Number.
The thickness of PVC roof tiles may vary, but common thickness ranges are between 2.0mm and 3.0mm. The specific thickness depends on the design and usage requirements of the product.
PVC roof tiles are usually available in a variety of colors, such as white, blue, green, red, brick red, gray, yellow, etc., to suit different architectural styles and aesthetic needs.
We have our own design department and provide design services to thousands of partners.
we are factory
Yes, although PVC roof tiles have a long service life and good durability, they still need regular maintenance and care. This includes clearing debris from the roof and checking whether the tiles are damaged or loose.
When cleaning PVC roof tiles, avoid using sharp or hard tools to scratch the surface to avoid damaging the tiles. You can use a soft brush or a high-pressure water gun for cleaning, but be careful not to use too much water pressure to avoid damaging the tiles or affecting their waterproof performance.
